GLADEN RS-X 6.5
● 6,5" / 16,5 cm
● Power handling: 350 / 250 Watts
● 4 Ohm impedance
ÜBERSICHT GLADEN RS-X 6.5
● Cast aluminum basket
● Black nomex spider
● Paper membrane
● PP - dust cap
● 10,5 l ventilated enclosures
● 6 l closed enclosure
TECHNICAL DATA GLADEN RS-X 6.5
MATERIAL:
Cone:Paper
Spider:Nomex
Surround:Foam
Coil former:Aluminum
Basket:Aluminum
Dust Cap:PP
SPECIFICATIONS:
DC resistance (Rdc):3,33 Ω
Nominal impedance (ZN):4 Ω
Resonance frequency (fs):54,9 Hz
Voice coil diameter:50 mm
Mechanical Q factor (Qms):5,59
Electrical Q factor (Qes):0,70
Total Q factor (Qts):0,62
Moving mass (Mms):62,3 g
Effective piston area (Sd):143 cm²
Mechanical resistance (Rms):3,85 kg/s
Compliance (Cms):135 mm/N
Force factor (BL):10,1 Tm
Equivalent air volume (Vas):3,88 cm³
Efficiency (η):0,33 %
SPL 2,83V/1m:85,4 dB
