GLADEN RS-X 10
● 10" / 25 cm
● Power handling: 450 / 300 Watts
● 4 Ohm impedance
OVERVIEW GLADEN RS-X 10
● Cast aluminum basket
● Black nomex spider
● Paper cone
● PP - dust cap
TECHNICAL DATA GLADEN RS-X 10
MATERIAL:
Cone:Paper
Spider:Nomex
Surround:Foam
Coil former:Aluminum
Basket:Aluminum
Dust Cap:PP
SPECIFICATIONS:
DC resistance (Rdc):3,74 Ω
Nominal impedance (ZN):4 Ω
Resonance frequency (fs):35,57 Hz
Voice coil diameter:2,5 inch
Mechanical Q factor (Qms):6,16
Electrical Q factor (Qes):0,49
Total Q factor (Qts):0,46
Moving mass (Mms):121,6 g
Effective piston area (Sd):346 cm²
Mechanical resistance (Rms):4,79 kg/s
Compliance (Cms):0,16 mm/N
Force factor (BL):13,82 Tm
Equivalent air volume (Vas):27,69 dm³
SPL 2,83V/1m:92,2 dB
