MOSCONI AERO 8|12 DSP

新一代MOSCONI DSP旗舰。只有极少数人面临着把“最好的”做得更好的任务。莫斯科尼的DSP 8to12 AEROSPACE也是如此，多年来一直是市场上最好的DSP之一，在高端领域仍然是“最先进的”。在这里，我们的开发人员通过有针对性的干预，成功地将关键领域和声音性能提升到一个新的水平。新的AERO 8|12 DSP现在配备了一个BT Plus端口，因此也与我们最新的创新，BARNIE -校准系统兼容。此外，它现在有一个通用接口，最多可支持16个通道。“主动的overall偏置”稳定是进一步提高声音性能的原因，它最大限度地减少了整个动态范围内发生的失真。通道分离，无论是在混合操作(高电平/低电平)还是在输入求和时，也再次进行了优化(Smart Dual ADC)。为了获得最佳的连接性和可安装性，AERO 8112 DSP现在具有USB-C端口和新的外壳，通过其设计满足现代安装。

OVERVIEW MOSCONI AERO 8|12 DSP

The new generation of the MOSCONI DSP flagship.

Only rarely one is faced with the task of making "the best" even better. This is also the case with the DSP 8to12 AEROSPACE by MOSCONI, which has always been among the best DSPs on the market for many years and is still "state of the art" in the high end segment. Here our developers succeeded in raising crucial areas and the sound performance to a new level with targeted interventions.

The new AERO 8|12 DSP is now equipped with a BT Plus port and thus also compatible with our latest innovation, the BARNIE - calibration system. In addition, it now has a universal interface for up to 16 channels.

An "active over-ALL bias" stabilization is responsible for the further increased sound performance, which minimizes distortions occurring in the entire dynamic range.The channel separation, whether in mixed operation (high level / low level) or when summing the inputs, has also been optimized again (Smart Dual ADC).

For best connectivity and installability, the AERO 8|12 DSP now has a USB-C port and a new housing that meets modern installations through its design.

TECHNICAL DATA MOSCONI AERO 8|12 DSP

INPUTS:

8 x RCA (Cinch), switchable high / low level with autosense

4 of them freely selectable as prioritized Auto-fade/Aux

1 x S/PDIF digital optical

1 x RCA digital COAX

1 x BT slot

ATOM Mixer menu with dynamic preset switching and "trigger" control

OUTPUTS:

12 x RCA analog

1 x S/PDIF optical (freely assignable, volume controlled)

12 V remote-out

EQUALIZER:

Fully parametric 30 band EQ, can also be used graphically, + 12 to - 12 dB, Q: 0.5 - 40

Fixed: channels front (1 - 6) channels rear (9 + 10)

Assignable channels: 7 + 8 = Front, Rear 11 + 12 = Sub, Center, Free

FILTERS:

10 per channel freely configurable, (setting without sound interruption)

Highpass, lowpass, shelf, notch, allpas, peak EQ

Slope 6 - 120 dB/Oct, variable Q, time and level

OTHER:

Compatible with BARNIE measurement system

Time correction 0 - 12 ms (0.005 ms steps) (setting without sound interruption)

Input-Delay (Channels 1 - 6) for the correction of runtime-delayed plant systems

Phase inversion 0 - 180°

Level adjustment outputs (0.5-dB steps)

Mute function

4 x preset memory (switching without sound interruption)

Dimensions: 200 x 125 x 40 mm (incl. mounting flange)

DOWNLOAD

详细参数.pdf

下载链接

https://www.gladen.com/en-us/downloads
