GLADEN RC 600C1
● 4 Ohm: 1 x 360 Watts
● 2 Ohm: 1 x 560 Watts
● CLASS-D
OVERVIEW GLADEN RC 600C1
● Mono amplifier CLASS-D
● High-level with auto sense
● Double-sided PCB and
● SMD components
● Optional remote control module
Functions:
● Input with low or high level signal
● High level with auto-sense function (no remote control signal required)
● Low-pass filter from 40 to 220 Hz
● Subsonic filter from 10 to 50 Hz
● Bass boost: - 6 dB, 0 dB or + 6 dB
● RC-RTC wired remote control (optional)
● Overheat, overload, short circuit and speaker DC protection
● Solid, heavy aluminum heat sink
TECHNICAL DATA GLADEN RC 600C1
OUTPUT POWER:
RMS power, 4 Ohm:360 Watts
RMS power, 2 Ohm:560 Watts
SPECIFICATIONS:
Thermal protection:80 °C
THD @ 4 Ω / 50% Pmax:0.5 %
Signal/noise:100 dB
Band width +- 3 dB:20 - 220 Hz
Input sensitivity:0.2 - 10 Vrms
Low input impedance:17 kΩ
High input impedance:50 Ω (with RC-HLT)
Damping @ 80 Hz:60
Power consumption, idle:0.9 A
Weight:1.72 kg
Dimensions:Length: 208 mm x Width: 150 mm x Height: 50 mm
