GLADEN ZERO 10 PRO
● 25 cm / 10"
● 600 / 400 Watts
● 4 Ohm impedance
OVERVIEW GLADEN ZERO 10 PRO
● High-end subwoofer
● Cast aluminum basket
● Nomex spider
● Lasered back plate
● Stitched strands
● GLADEN PFP technology: paper / foam / paper compound diaphragm
● Made in Germany
TECHNICAL DATA GLADEN ZERO 10 PRO
MATERIAL:
Cone:PFP
Surround:Rubber
Basket:Aluminum
Spider:Nomex
Coil former:Aluminium
Dust Cap:Paper
SPECIFICATIONS:
Power:Pe 400/600 RMS/Nom
DC resistance:Rdc 3,4 Ω
Nominal impedance:ZN 4 Ω
Resonance frequency:fs 30 Hz
Voice coil diameter:2,5 inch
X-Max:+/- 12,5 mm
Mechanical Q factor:Qms 7,34
Electrical Q factor:Qes 0,49
Total Q factor:Qts 0,46
Moving mass:md 98,57 g
Effective piston area:Sd 346 cm2
Mechanical resistance:Rms 2,77 kg/s
Compliance:Cms 0,28 mm/N
Force factor:BL 10,9 Tm
Equivalent air volume:Vas 47,25 dm3
SPL 2,83V/1m:90 dB
External diameter:260 mm / 10,24 inch
Installation diameter:236 mm / 9,29 inch
Installation depth:149 mm / 5,87 inch
Magnet diameter:155 mm / 6,10 inch
